Specifications:-
Brand: Celestron
Optical Design: Newtonian Reflector
Aperture: 114mm (4.48″)
Focal Length: 1000mm (39.37″)
Focal Ratio: f/8.77
Focal Length of Eyepiece 1: 20mm (0.79″) with built-in erect image corrector
Magnification of Eyepiece 1: 50x
Focal Length of Eyepiece 2: 10mm (0.4″) standard
Magnification of Eyepiece 2: 100x
Barlow Lens: Not Included
Finderscope: Built-in StarPointer™ red dot finderscope
Star Diagonal: None
Optical Tube: Aluminum
Highest Useful Magnification: 269x
Lowest Useful Magnification: 16x
Limiting Stellar Magnitude: 12.8
Resolution (Rayleigh): 1.22 arc seconds
Resolution (Dawes): 1.02 arc seconds
Light Gathering Power (Compared to human eye): 265x
Secondary Mirror Obstruction: 44mm (1.73″)
Secondary Mirror Obstruction by Diameter: 38%
Secondary Mirror Obstruction by Area: 14%
Optical Coatings: TBD
Optical Tube Length: 508mm (20″)
Optical Tube Diameter: TBD
Optical Tube Weight: TBD
Dovetail: CG-5 Dovetail bar
MOUNT INFO:
Mount Type: Manual German Equatorial
Height adjustment range (includes mount and tripod): 812.8mm – 1295.4mm (32″ – 51″)
Tripod Leg Diameter: 31.75mm (1.25″) steel
Accessory Tray: Yes
Tripod Weight: 7.6 lbs (3.44 kg)
Slew Speeds: Manual
Dovetail Compatibility: CG-5 saddle plate
Software: Celestron Starry Night Basic Edition Software and SkyPortal App
PHONE ADAPTER INFO:
Phone Compatibility: Any smartphone
Comptabile Optics: Any 1.25″ eyepiece supplied with PowerSeeker and AstroMaster telescope kits or any eyepieces with a 34mm outside diameter
Dimensions: 165mm x 114.3mm 25.4mm (6.5″ x 4.5″ x 1″)
Weight: 2 oz
Features:-
Unmagnified to make finding objects easier and star-hopping navigation faster
Illuminated red center aiming dot is easy to see without affecting night-adjusted vision
Tray to hold eyepieces, lights, and accessories
Spiked feet add stability on uneven/soft ground
Manual German equatorial
Dual slow-motion control cables enable fine adjustments with reduced vibrations
Altitude adjustment screws lock setting
Etched Right Ascension and Declination scales
Removable counterweight bar
Two 2.6 lb counterweights properly balance OTA and accessories for smooth movement
Dovetail plate enables fast assembly and break-down
Highly reflective aluminum-coated mirrors improve light transmission, color rendition, and contrast
Resolution: 1.22 arcsec, Rayleigh; 1.02 arc sec, Dawes
Secondary mirror obstruction: 31% by diameter, 10% by area
